Portable Multisport Scoreboards
High-resolution LED scoreboards for hockey, soccer, netball, basketball, and indoor sports
RSS Multisport Scoreboard
The RSS Multisport Scoreboard is a portable electronic display designed for sports scoring. It displays game/period clock, home team score, and away team score with visibility up to 50 metres in full sunlight. Available in indoor and outdoor versions — the outdoor version features higher brightness for direct sunlight, with slightly higher power requirements.
Ideal For
- ✓ Hockey
- ✓ Soccer / Football
- ✓ Netball
- ✓ Basketball
- ✓ Futsal
- ✓ Indoor sports generally
Key Benefits
Affordable
Competitive pricing for hire or purchase. Weekend hire from just $100 + GST.
Phone Control
Score via smartphone or tablet app over Wi-Fi. Range up to 50 metres.
Battery Powered
12V DC battery operation. No mains power required for portable use.
Outdoor Ready
High-brightness display visible in full sunlight. Adjustable brightness settings.
Easy Scoring via Wi-Fi
Control the scoreboard from any phone or tablet using the built-in Wi-Fi interface — no app download required, just open a web browser
Live Scoring
Game Setup
Technical Specifications
P2.5 Model (Indoor / Small Outdoor)
| Specification | Detail |
|---|---|
| Pixel Pitch | 2.5 mm |
| Pixels | 256 × 128 |
| Screen Size | 640 × 320 mm |
| Dimensions | 740(L) × 420(H) × 100(D) mm |
| Weight | 12.4 kg |
| Brightness | 1000 cd/m² |
| Viewing Distance | 2.5–50 m |
| Max Power | ~20 W |
P5 Model (Outdoor)
| Specification | Detail |
|---|---|
| Pixel Pitch | 5 mm |
| Pixels | 192 × 64 |
| Screen Size | 960 × 320 mm |
| Dimensions | 1000(L) × 365(H) × 140(D) mm |
| Weight | 17.5 kg |
| Brightness | High (outdoor rated) |
| Viewing Distance | 5–75 m |
| Max Power | ~67 W |
Common Specifications
| Specification | Detail |
|---|---|
| Viewing Angle | >140° horizontal |
| Wi-Fi Range | ~50 m |
| LED Lifespan | >100,000 hours |
| Enclosure | Aluminium |
| Power Supply | 12V DC nominal |
| Operating Temp | -10°C to 60°C |
| Storage Temp | -25°C to 85°C |
| Mounting | PA speaker stand compatible |
Mounting Options
Flexible setup options for any venue or event
Flexible Power Options
Run from AC mains power, or battery — Lead-Acid (SLA) or Lithium options are compatible.
A battery pack is the perfect companion to your scoreboard where mains power is not available. With a long-life battery, housed in a rainproof enclosure, you are sure to get many hours of scoreboard operation before charging is required.
Estimated Battery Run Times (SLA)
| Battery Size | Estimated Run Time |
|---|---|
| 22Ah | ~2 hours |
| 60Ah | ~6 hours |
| 100Ah | ~10 hours |
PA Speaker Stand
Compatible with standard PA speaker stands for maximum portability. Use your existing equipment for quick deployment.
Carry Handle
Built-in carry handle makes transportation easy. Lightweight aluminium construction at just 12.4kg.
Hire or Purchase
Weekend hire from $100 + GST. Available for purchase from $1,990 + GST. Contact us for long-term hire rates or to order.
Get a Quote
